(03 Month Warranty) Cpu – Support For 8th Generation Intel® Core™ I7 / I5 / I3 Processors (Lga1151 Package) L3 Cache – Varies By Cpu (Refer To “cpu Support List” For Details) Chipset – Intel® Z370 Express Chipset Memory – 4 X Ddr4 Dimm Sockets, Up To 64 Gb Memory Architecture – Dual Channel Supported Memory Speeds – Ddr4 4000(O.c.) / 3866(O.c.) / 3800(O.c.) / 3733(O.c.) / 3666(O.c.) / 3600(O.c.) / 3466(O.c.) / 3400(O.c.) / 3333(O.c.) / 3300(O.c.) / 3200(O.c.) / 3000(O.c.) / 2800(O.c.) / 2666 / 2400 / 2133 Mhz Memory Type Support – Ecc Un-buffered Dimm (Operates In Non-ecc Mode), Non-ecc Un-buffered Dimm, Xmp Support (Refer To “memory Support List” For Details) Onboard Graphics – Integrated Intel® Hd Graphics Display Outputs – • 1 X Dvi-d (Max 1920×1200@60hz) (No D-sub Adapter Support) • 1 X Hdmi (Max 4096×2160@30hz, Hdmi 1.4, Hdcp 2.2) Shared Memory – Max 1 Gb Audio – Realtek® Alc892 Codec, High Definition Audio, 2/4/5.1/7.1-channel, S/pdif Out Support Lan – Intel® Gbe Lan (10/100/1000 Mbit) Expansion Slots – • 1 X Pci Express X16 Slot (Running At X16) • 1 X Pci Express X16 Slot (Running At X4) • 2 X Pci Express X1 Slots (All Pcie Slots Conform To Pcie 3.0 Standard) Multi-gpu Support – Amd Quad-gpu Crossfirex™ / 2-way Amd Crossfire™ Storage Interface – • 1 X M.2 (Socket 3, Type 2242/2260/2280/22110 Sata & Pcie X4/x2 Ssd Support) • 1 X M.2 (Socket 3, Type 2242/2260/2280 Pcie X4/x2 Ssd Support) • 6 X Sata 6gb/s Ports • Raid 0, 1, 5, 10 Support • Intel® Optane™ Memory Ready Usb – • 1 X Usb Type-c™ (Usb 3.1 Gen 1) On Back Panel • 8 X Usb 3.1 Gen 1 (6 Rear, 2 Internal) • 4 X Usb 2.0/1.1 (Internal Headers) Internal I/o Connectors – • 1 X 24-pin Atx Main Power • 1 X 8-pin Atx 12v Power • 1 X Cpu Fan Header • 3 X System Fan Headers • 1 X Rgb Led Strip Header • 6 X Sata 6gb/s • 2 X M.2 Sockets • 1 X Front Panel Header • 1 X Front Panel Audio Header • 1 X S/pdif Out Header • 1 X Usb 3.1 Gen 1 Header • 2 X Usb 2.0/1.1 Headers • 1 X Tpm Header (2×6 Pin, Gc-tpm2.0_s Module) • 1 X Serial Port Header • 1 X Parallel Port Header • 1 X Clear Cmos Jumper Back Panel Connectors – • 1 X Ps/2 Keyboard/mouse Combo Port • 1 X Dvi-d Port • 1 X Hdmi Port • 1 X Usb Type-c™ (Usb 3.1 Gen 1) • 6 X Usb 3.1 Gen 1 Ports • 1 X Rj-45 Lan Port • 6 X Audio Jacks (Center/subwoofer, Rear, Side, Line In, Line Out, Mic In) I/o Controller – Ite® Controller Chip Hardware Monitoring – Voltage, Temperature, Fan Speed Detection, Overheat & Fan Fail Warning, Fan Speed Control (Fan Control Depends On Cooler Used) Bios – Dualbios™ (2 X 128 Mbit Flash), Ami Uefi Bios, Pnp 1.0a, Dmi 2.7, Wfm 2.0, Sm Bios 2.7, Acpi 5.0 More Details Visit https://www.gigabyte.com/ You Are Interest In This Type Of Product Here Are Our https://computerzone.lk/shop
