$62.98
$117.77
Description Camera Image Sensor 1/2.7" Progressive Scan CMOS Min. Illumination Color: 0.028 Lux @(F2.0, AGC ON) Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes Day &Night IR Cut Filter Wide Dynamic Range DWDR DNR 3D DNR Axis Adjustment Pan: 0° to 355°, tilt: 0° to 75° Lens Aperture F2.0 FOV 2.8 mm, horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° 4 mm, horizontal field of view: 86°, vertical FOV: 46°, diagonal FOV: 102° Lens Mount M12 Focal Length 2.8/4 mm Illuminator IR Range Up to 30 m Wavelength 850 nm Network Alarm Trigger Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full Network Storage Support built-in microSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR Protocols TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour API ONVIF (PROFILE S, PROFILE G), ISAPI Simultaneous Live View Up to 6 channels User/Host Up to 32 users. 3 levels: administrator, operator and user Client Wired network: Hik-Connect, iVMS-4200, iVMS-5200, iVMS-4500 Wi-Fi: iVMS-4200, iVMS-5200, iVMS-4500 *Wi-Fi connection with Hik-Connect directly is not possible. Web Browser IE 8 , Chrome 31.0-44, Firefox 30.0-51, Safari 8.0 Video Max. Resolution 1920 × 1080 Main Stream 50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) Sub Stream 50Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) Video Compression Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG H.264 Type Baseline Profile/Main Profile/High Profile H.265 Type Main Profile Video Bit Rate 32 Kbps to 8 Mbps Audio Audio Compression G.711/G.722.1/G.726/MP2L2/PCM Audio Bit Rate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) Audio Sampling Rate 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz Smart Feature-Set Region Of Interest Support 1 fixed region for main stream Image Image Enhancement BLC/3D DNR Image Setting Saturation, brightness, contrast and sharpness are adjustable via client software and web browser Day/Night Switch Auto/Scheduled/Day/Night Interface Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port Audio 1 Built-in mic, mono sound On-Board Storage Built-in microSD/SDHC/SDXC slot, up to 128 GB General Firmware Version V5.5.98 General Function One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter Reset Yes Startup And Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) Power Supply 12 VDC ± 25%, Ø5.5 mm coaxial plug power Power Consumption And Current 12 VDC, 0.4 A, max. 5 W, <20 dBm Material Plastic
