DescriptionA900-IMA16D SpecificationsTypeASR 900 16 port T1/E1 Interface Module, Requires patch panelPort density16-port T1/E1 TDMPower draw14W typical, 18W maximumModule shipment weight2.13 lbsModule shipment package size (LxWxH)15.44 x 9.44 x 4.31 inchesEnvironmental specifications –40 to 65ºC (–40 to 149ºF) operating temperature (using Industrial temperature XFP, SFP, and SFP optics)0 to 40ºC (32 to 104ºF) operating temperature (CPAK and QSFP optics)Relative humidity5 to 95%, noncondensingStorage environmentTemperature: –40 to 70ºC (–40 to 158ºF) altitude: 4570 m (15,000 ft)MTBF at 40ºC (104ºF) operating temperature787,060 hoursReliability and availabilityOIR field-replaceable SFP optics modulesSupport for both 1 1 SONET Automatic Protection Switching (APS) and SDH Linear Multiplexer Section Protection (MSP) protocolsSingle interface module software resetRolling software upgrade, interface module by interface module
